Cooper&Hunter 48,000 BTU 4 TON 16.2 SEER Ducted Mini Split and Heat Pump Inverter System with Multi Position Air Handler Unit with Wi-Fi Included - Choose your Installation Kit and Auxiliary Heat Strip Size - CH-48AHU + CH-N48LCU-230VO
Summary
Air handler units offer a versatile replacement for traditional air conditioning systems that can be connected to pre-existing duct work, but with smaller units that are quieter (variable speed fan motor) and more energy efficient. The air handlers, which are available in 18K, 24K, 36K, 48K, and 60K Btu/h models, can be installed vertically, horizontally, or downward. These units can be connected to any 24V wall thermostat and are compatible with standard 18K to 60K Btu/h outdoor models or Hyper Heat upgrades, which provide dependable heating in ambient temperatures as low as -22°F.
Models ranging from 36K to 60K Btu/h work for single zone applications, while 18K and 24K Btu/h are compatible with both single and multi zone condensers. Notable features include high static pressure and Quiet Operation.
Included in Your Order:
Cooper & Hunter Single Zone Air Handler System (48,000 BTU)
Outdoor Unit: 48,000 BTU (1pc) – Model: CH-N48LCU-230VO
Indoor Unit: 48,000 BTU (1pc with remote) – Model: CH-48AHU
Optional Installation Kit (16ft, 25ft, or 50ft options available) Must be selected above.Â
Optional Auxillary Heat Strip (5KW, 10KW, or 15KW, 20KW options available)Â Must be selected above.Â
Wi-Fi Enabled Thermostat
Wireless Remote Control
Installation Manual
User's Manual
Manufacturer Warranty
Key Features:
- Auto-Swing for horizontal louvers
- Variable-speed fan motor
- 46° Freeze Protection
- Turbo Mode
- Self-Clean Function
- Eco Mode
- Follow Me Mode
- Remote Control included
- Smart Kit ready with downloadable C&H remote app
Important
All units must be installed by a licensed HVAC professional for the warranty to be valid. Registration is required within 60 days of installation and can be completed online or by phone. The installation kit is necessary for the system to function. Ensure that you have selected the desired installation kit above. Visit https://cooperandhunter.us/warranty to register your product under Warranty, and call 786-953-6706 EXT 3 for This kit comes with Pre-Flared 99% Copper Lines, Data Communication Wires, PVC Drainage Attachment, Wrapping Bands, etc.
Multi-Position Air Handler Systems
Model | SKU |
---|---|
18,000 BTU Air Handler with Optional Installation Kit 230V |
CH-M18AHU-W + CH-ES18-230VO |
24,000 BTU Air Handler with Optional Installation Kit 230V | CH-M24AHU-WÂ +Â CH-ES24-230VO |
36,000 BTU Air Handler with Optional Installation Kit 230V | CH-36AHU-W + CH-N36LCU-230VO |
OLMOÂ 36,000 BTU Air Handler with Optional Installation Kit 230VÂ | OS-EAH36-230VI + OS-EAH36-230VO |
48,000 BTU Air Handler with Optional Installation Kit 230V | CH-48AHU + CH-N48LCU-230VO |
60,000 BTU Air Handler with Optional Installation Kit 230V |
CH-60AHU + CH-N60LCU-230VO |
HYPERÂ Models | SKU |
---|---|
18,000 BTU Air Handler with Optional Installation Kit 230VÂ |
CH-M18AHU +Â CH-HPR18-230VO |
24,000 BTU Air Handler with Optional Installation Kit 230V | CH-M24AHU + CH-HPR24-230VO |
36,000 BTU Air Handler with Optional Installation Kit 230V | CH-36AHU-W +Â CH-NHPR36LCU-230VO |
48,000 BTU Air Handler with Optional Installation Kit 230V | CH-48AHU + CH-N48LCU-230VO |
60,000 BTU Air Handler with Optional Installation Kit 230V |
CH-60AHU + CH-N60LCU-230VO |
Â
Other Ducted Systems
(Slim Ducts - Concealed Duct)
Model | SKU |
---|---|
18,000 BTU Air Handler with Optional Installation Kit 230V |
CH-M18AHU-WÂ +Â CH-ES18-230VO |
24,000 BTU Air Handler with Optional Installation Kit 230V | CH-M24AHU-WÂ +Â CH-ES24-230VO |
36,000 BTU Air Handler with Optional Installation Kit 230V | CH-36AHU-W + CH-N36LCU-230VO |
OLMOÂ 36,000 BTU Air Handler with Optional Installation Kit 230VÂ | OS-EAH36-230VI + OS-EAH36-230VO |
48,000 BTU Air Handler with Optional Installation Kit 230V | CH-48AHU + CH-N48LCU-230VO |
60,000 BTU Air Handler with Optional Installation Kit 230V |
CH-60AHU + CH-N60LCU-230VO |
HYPERÂ Models | SKU |
---|---|
18,000 BTU Air Handler with Optional Installation Kit 230VÂ |
CH-M18AHU +Â CH-HPR18-230VO |
24,000 BTU Air Handler with Optional Installation Kit 230V | CH-M24AHU + CH-HPR24-230VO |
36,000 BTU Air Handler with Optional Installation Kit 230V | CH-36AHU-W +Â CH-NHPR36LCU-230VO |
48,000 BTU Air Handler with Optional Installation Kit 230V | CH-48AHU + CH-N48LCU-230VO |
60,000 BTU Air Handler with Optional Installation Kit 230V |
CH-60AHU + CH-N60LCU-230VO |
Warranty
- 7 year compressor limited warranty
- 5 year parts limited warranty (must be installed by a licensed HVAC technician)
- 1 year remote control
Technical Information
Indoor Unit:Â CH-48AHU
Specification | Details |
---|---|
System Type | Single-zone unit |
Filter Dimensions (W x D) | 19.40 x 20.35 inches |
BTU Rated | 48,000 BTU |
Power Source | 208-230V, 1Ph, 60Hz |
Dehumidification Value | 10.82 pints/day |
Refrigerant Type | R410A |
Voltage Range (V) | 187-253 |
Packing Dimensions (W x D x H) | 26.57 x 24.41 x 52.56 inches |
Controller | RG10D-standard remote & 120X or 120N wire controller |
Refrigerant Piping (Liquid/Gas side) | 3/8" - 5/8" |
EER2 | 8.6 |
SEER2 | 16.2 |
Unit Net/Gross Weight | 132.50 / 155.87 lbs |
Unit Dimensions (W x H x D) | 21.02 x 21.02 x 49.02 inches |
Operation Range - Heating (°F) | 32 ~ 86 |
Operation Range - Cooling (°F) | 60 ~ 90 |
Minimum Circuit Ampacity | 7.5A |
Max Fuse | 15A |
Indoor Noise Level (H/M/L) | 53.5 / 47 / 43.5 dB |
Indoor Air Flow (H/M/L) | 1,470.59 / 1,282.35 / 1,094.12 / 905.88 CFM |
ESP Range | 0 - 0.8 |
Drainage Water Pipe Diameter | 1 inch |
Outdoor Unit:Â CH-N48LCU-230VO
Specification | Details |
---|---|
System Type | Single-zone unit |
BTU Rated | 48,000 BTU |
Power Source | 208-230V, 1Ph, 60Hz |
Dehumidification Value | 11.01 pints/day |
Max Pipe Length | 213.25 ft |
Refrigerant Type | R410A |
Voltage Range (V) | 187-253 |
Packing Dimensions (W x D x H) | 43.11 x 19.49 x 58.27 inches |
Refrigerant Piping (Liquid/Gas Side) | 3/8" - 5/8" |
HSPF2-5 | 7.2 |
HSPF2-4 | 9.2 |
EER2 | 8.2 |
Cooling Capacity (Min/Max) (BTU/h) | 48,000 (13,000 ~ 51,900) |
SEER2 | 15.3 |
Unit Net/Gross Weight | 219.14 / 249.12 lbs |
Unit Dimensions (W x H x D) | 37.48 x 16.34 x 52.48 inches |
Refrigerant Precharge | 25 |
Outdoor Noise Level | 62.5 dB |
Outdoor Air Flow | 4,500 CFM |
Minimum Circuit Ampacity | 36.5A |
Max Fuse | 50A |
Max Height Difference Between Indoor and Outdoor Unit | 98.42 ft |
Heating Capacity (Min/Max) (BTU/h) | 55,000 (16,000 ~ 58,000) |
COP | 2.94 |
Ambient Temperature - Heating (°F) | -13 ~ 75 |
Ambient Temperature - Cooling (°F) | 5 ~ 122 |
Additional Refrigerant Charge (3/8 liquid line) | 0.32 |
