MRCOOL VersaPro™ 48k BTU Heat Pump Package Unit | MPH481H413B
Summary
Even in the worst of weather conditions, the MRCOOL® VersaPro™ 48K BTU 13.4 SEER2 Package Heat Pump is able to maintain your ultimate comfort level within your home, providing high-performance cooling and powerful heating capabilities within a single, easy-to-install system. Encased in a resilient anti-rust, power-painted galvanized steel cabinet, this heating and cooling solution offers an optimal balance of affordability and durability. The unit's high-efficiency compressors function smoothly, ensuring quiet and consistent performance. Internal safeguards protect against high and low pressures, coil temperature variations, and power surges. With an ECM blower motor and advanced copper tube/aluminum fin coils, this package heat pump delivers exceptional efficiency using R410A refrigerant.
Important
Registration required for 10-year warranty. Optional electric heat kit available (5/8/10/15/20kW). AHRI Certified and ETL Listed for quality assurance.
Key Features
- Complete 4-ton packaged heat pump system
- Durable galvanized steel cabinet with anti-rust coating
- High efficiency scroll compressor
- ECM condenser fan motor (1/4 HP, 980 RPM)
- PSC blower motor (3/4 HP)
- Copper tube/aluminum fin coil for optimal heat transfer
- Quiet horizontal discharge design
- Optional electric heat kit available (5/8/10/15/20kW)
- Internal safeguards against operational extremes
- 13.4 SEER2 efficiency rating
- R410A eco-friendly refrigerant (106 oz)
Complete Technical Specifications
| SKU | MPH481H413B |
| UPC | 840255582490 |
| Certifications | ETL Listed, AHRI Certified |
| Cooling Capacity | 48,000 BTU (4 Ton) |
| Heating Capacity | 48,000 BTU |
| Efficiency Rating | 13.4 SEER2 |
| Refrigerant | R410A (106 oz) |
| Electrical | 208/230V 1 Phase 60 Hz |
| Electrical Details | 26.8A Min Circuit Ampacity, 40A Max Fuse Breaker |
| Compressor Type | Scroll |
| Condenser Fan Motor | ECM, 1/4 HP, 980 RPM |
| Blower Motor | PSC, 3/4 HP |
| Net Dimensions (HxWxD) | 33.07" x 58.50" x 42.05" |
| Net Weight | 442 lbs |
| Shipping Dimensions | 34.13" x 58.74" x 42.36" |
| Shipping Weight | 451 lbs |
Performance Features
| Cabinet Construction | Galvanized steel with power-painted finish |
| Coil Design | Copper tube/aluminum fin |
| Discharge Design | Horizontal |
| Safety Features | High/low pressure protection, coil temp protection, power surge protection |
| Optional Accessories | Electric heat kit (5/8/10/15/20kW) |
Warranty Information
- 10 Year Parts Warranty - With registration within 90 days
- 10 Year Compressor Warranty - With registration within 90 days
- 5 Year Parts Warranty - Without registration
- 5 Year Compressor Warranty - Without registration
Manuals & Certifications
- Product Brochure
- Installation Manual
- Spec Sheet
- Service Manual
- Warranty Registration
- AHRI Certification
Safety Information
PROPOSITION 65 WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Advanced Technology
The MRCOOL VersaPro™ 48K BTU Package Heat Pump features a high-efficiency scroll compressor and ECM condenser fan motor for optimal performance and energy savings. The copper tube/aluminum fin coil design ensures excellent heat transfer efficiency, while the galvanized steel cabinet provides superior durability and corrosion resistance. The horizontal discharge design contributes to quiet operation, making this 4-ton unit suitable for residential and light commercial applications where noise is a concern.
Installation Advantages
As a complete packaged system, the VersaPro™ 48K BTU unit simplifies installation by combining all components in a single, durable enclosure. The robust construction withstands harsh weather conditions, and the internal safeguards protect the system from various operational extremes. The optional electric heat kit (available in 5kW to 20kW configurations) provides supplemental heating capability when needed, offering flexibility for different climate requirements and ensuring year-round comfort.
