MRCOOL 2.5 Ton VersaPro® Central Ducted Heat Pump Condenser | R-454B – MVP-30-HP-C-230A00-O
Â
Summary
The 2.5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser (Model MVP-30-HP-C-230A00-O) delivers efficient, year-round comfort with a compact, side-discharge design. Its variable-speed DC inverter helps maintain steady temperatures while keeping utility costs in check. Pairs seamlessly with the VersaPro® Central Ducted Air Handler and includes a MRCOOL® Smart Thermostat for simple, app-enabled control. Uses eco-forward R-454B refrigerant.
Important
R-454B refrigerant. Variable-speed inverter. Side-discharge, compact footprint. Smart thermostat included.
What's Included
- Outdoor Condenser (MVP-30-HP-C-230A00-O)
- MRCOOL® Smart Thermostat (Wi-Fi/app compatible)
- Installation & Owner’s Manual
- Service Manual
- Warranty Information
Features
- SEER2 17 / EER2 10.7; HSPF4 8.5 / HSPF5 6.6
- Eco-forward R-454B refrigerant
- Variable-speed DC inverter for precise comfort
- Quiet operation (~60 dBA), compact side-discharge chassis
- Painted galvanized steel construction
- Self-diagnostics for easier service
Technical Specifications
| Brand / Series | MRCOOL / VersaPro® Central Ducted Condenser |
| Model | MVP-30-HP-C-230A00-O |
| GTIN | 00840255582704 |
| UPC | 840255582704 |
| Unit Type | Split System Heat Pump |
| Equipment Type | Condenser |
| SEER2 | 17 |
| EER2 | 10.7 |
| HSPF-4 | 8.5 |
| HSPF-5 | 6.6 |
| CFM (Outdoor Airflow) | 3001.8 |
| Tonnage | 2.5 |
| Cooling Capacity (BTU) | 30,000 |
| Heating Capacity (BTU) | 31,000 |
| Voltage / Phase / Cycle | 208–230 V / 1-Phase / 60 Hz |
| Max Fuse / Breaker (A) | 25 |
| Min Circuit Ampacity (A) | 22.5 |
| Color | Gray |
| Refrigerant | R-454B |
| Factory Charge (oz) | 91.71 |
| Decibel Rating (dBA) | ~60 |
| Liquid / Suction Line Sizes | 3/8" / 3/4" |
| Wi-Fi / App Compatibility | Yes / Yes (Smart Thermostat included) |
| Certifications | ETL Certified; AHRI Certified; ENERGY STAR®: No |
| Net Dimensions (W × D × H) | 37.24" × 16.14" × 31.89" |
| Net / Gross Weight | 141.76 lbs / 152.34 lbs |
| Gross Dimensions (W × D × H) | 42.91" × 19.68" × 34.84" |
| Contains Electronics / Chemicals / Compressed Gas | Yes / Yes / Yes |
Airflow, Refrigerant & Installation Limits
| Outdoor Airflow | 3001.8 CFM |
| Line Set Sizes | Liquid 3/8" • Suction 3/4" |
| Line Length & Elevation | See Installation/Service Manual for rated & max lengths and elevation limits. |
| Additional Refrigerant | See manual for charge adjustment per added line length. |
Compatibility & Pairing
| Works With | VersaPro® Central Ducted Air Handler (matching capacity) |
Warranty Information
- Base Parts Warranty: 10 Years (limited)
- Base Compressor Warranty: 10 Years (limited)
Manuals & Downloads
- Brochure (Gen 2)
- Installation & Owner’s Manual
- Performance Specs
- Condenser Service Manual
- Heat Kit Manual (optional accessory)
Safety & Install Notes
- Install on a solid, level base; follow clearances and anchoring guidance.
- Dedicated 208/230V, 1-phase circuit; include proper disconnect and follow wiring/torque specifications.
- Use specified line sizes; evacuate, leak-check, and charge per R-454B procedures.
- Comply with national/local codes; qualified personnel only.
Environmental & Efficiency Features
Low-GWP R-454B and inverter technology help reduce environmental impact and energy use while maintaining steady comfort.
