Home 12,000 BTU Milano Series
Milano Series

Bravo Milano Series 3-Zone Mini Split AC & Heat Pump -- 30,000 BTU (2.5 Ton), Wall Mount Units (9K+12K+12K BTU), Inverter Technology, 208-230V, Heating & Cooling

SKU BRV-M30-230VO + BRV-M09WM-230VI + 2X BRV-M12WM-230VI Wall Mount208-230V
$2,323.73 $2,581.92 Save $258.19 (9%)
In StockShips in 1-2 business days
High efficiency. Quiet performance. Easy installation.

A smart, reliable choice for year-round comfort.

Best for 9K room setups:
  • Small bedrooms
  • Home offices
  • Nurseries
  • Small additions
12,000 BTU
Cooling
12,000 BTU
Heating
See specs
Quiet Inside
See specs
High Efficiency

Brand Information

Bravo
Support Number
(888) 293-9252
Official Site
Bravo Official Site
Product Overview Full product description Read the longer product copy, features, and application notes.

CLICK HERE TO CONTACT US FOR CUSTOM QUOTES AND QUESTIONS

CLICK TO CALL US 737-738-6329 FOR ANY QUESTIONS

Bravo Milano Series 3-Zone Mini Split AC & Heat Pump -- 30,000 BTU (2.5 Ton), Wall Mount Units (9K+12K+12K BTU), Inverter Technology, 208-230V, Heating & Cooling


Summary

The Bravo Milano 3-Zone Mini Split Wall-Mounted System offers a sleek, efficient, and reliable solution for personalized climate control in residential or light commercial settings. This system features three indoor units (9K, 12K, and 12K Btu/h) connected to a 30K Btu/h outdoor unit, delivering powerful and precise heating and cooling exactly where you need it.

Each wall-mounted unit features a modern, low-profile design that blends seamlessly with most interior spaces. Designed for single-room comfort, these units automatically adjust their performance based on room conditions to maintain consistent temperature and efficiency.

Equipped with a SMART APP, the Bravo Milano system allows full remote control of temperature, fan speed, and operation mode from any smart device. With a SEER2 rating of 23, this system offers quiet performance, high energy efficiency, and year-round comfort you can count on.


Included in Your Order:

Bravo Milano 3-Zone Mini Split System

Outdoor Unit: 30,000 BTU (1pc) – Model: BRV-M30-230VO

Indoor Units:

- 9,000 BTU (1pc with remote) – Model: BRV-M09WM-230VI

- 12,000 BTU (2pcs with remote) – Model: BRV-M12WM-230VI

Optional Installation Kit (16ft, 25ft, or 50ft options available at checkout)

Wireless Remote Controls

Installation Manual

User's Manual

Manufacturer Warranty


Key Features:

  • Remote Control Included
  • Smart App: Connect from anywhere
  • Comfortable Sleep Mode
  • Super Mode
  • Eco Mode
  • Multiple Fan Speeds
  • Timer
  • Sleep Mode
  • Louver Auto Swing
  • Anti Mildew Mode
  • LED Display
  • Sleek matte finish
  • Turbo Function
  • Silent Function
  • Self-Cleaning Function
  • Follow Me Function
  • Activated Carbon Filter

3-Zone Combination Chart (BRV-M30-230VO Outdoor Unit)

Available 3-Zone Combinations
9K 9K 9K
9K 9K 12K
9K 9K 18K
9K 12K 12K
9K 12K 18K
12K 12K 12K
12K 12K 18K

Important Notes

All units must be installed by a licensed HVAC professional for the warranty to be valid. Registration is required within 60 days of installation and can be completed online or by phone. The installation kit is necessary for the system to function - please select your preferred size (16ft, 25ft, or 50ft) at checkout. This kit comes with Pre-Flared 99% Copper Lines, Data Communication Wires, PVC Drainage Attachment, Wrapping Bands, etc.


Complete Technical Specifications

Indoor Unit Specifications

BRV-M09WM-230VI (9K)

Specification Details
System Type Multi-zone unit
BTU Rated (Cooling) 9,000
BTU Rated (Heating) 9,000
Power Source 208-230V, 1-Phase, 60Hz
Max Fuse 5.0 A
Refrigerant Type R32
Indoor Air Flow 353 CFM
Noise Level 40 dB(A)
Dimensions (W×D×H) 31.02×11.50×7.80 inches
Packing Dimensions 34.65×14.57×11.42 inches
Net/Gross Weight 17.60/22.00 lbs
Refrigerant Piping 1/4" (liquid) / 3/8" (gas)
Operation Temperature Range 60.8-89.6°F

BRV-M12WM-230VI (12K)

Specification Details
System Type Multi-zone unit
BTU Rated (Cooling) 12,000
BTU Rated (Heating) 12,300
Power Source 208-230V, 1-Phase, 60Hz
Max Fuse 5.0 A
Refrigerant Type R32
Indoor Air Flow 353 CFM
Noise Level 42 dB(A)
Dimensions (W×D×H) 34.49×11.73×7.64 inches
Packing Dimensions 37.99×14.57×11.10 inches
Net/Gross Weight 19.80/24.27 lbs
Refrigerant Piping 1/4" (liquid) / 3/8" (gas)
Operation Temperature Range 60.8-89.6°F

Outdoor Unit Specifications: BRV-M30-230VO

Specification Details
Model Number BRV-M30-230VO
Rated Capacity (Cooling) 30,000 BTU/h (6,000-38,200)
Rated Capacity (Heating) 30,000 BTU/h (6,300-36,000)
Power Supply 208-230V, 1-Phase, 60Hz
SEER2 23
HSPF2 10.0
EER2 3.66
COP2 3.9
Minimum Circuit Ampacity 40.0 A
Max Fuse 40.0 A
Outdoor Air Flow 2,353 CFM
Noise Level 58 dB(A)
Refrigerant Type R32
Refrigerant Volume 67.0 OZ
Refrigerant Precharge 24.6 ft
Dimensions (W×D×H) 41.18×17.91×31.81 inches
Packing Dimensions 43.50×19.49×34.84 inches
Net/Gross Weight 148.8/157.6 lbs
Refrigerant Piping 1/4" (liquid) / 3/8" (gas)
Max Refrigerant Pipe Length 115 ft
Operating Temp (Cooling) -13~125.6°F
Operating Temp (Heating) -13-75.2°F

Warranty Information

  • 3-Year Compressor Limited Warranty
  • 3-Year Parts Limited Warranty (must be installed by a licensed HVAC technician)

Note: Warranty valid only when installed by licensed HVAC technician and registered within 60 days of installation.


Manuals & Downloads





Specs & Documents Product details Open technical specs, manuals, videos, and product documents.

Technical Data

Specs, manuals, videos, and product documents

Loading technical data…

Product FAQs

Product FAQs

Helpful answers matched to this product, brand, specs, and configuration.
What is Bravo?

Bravo is a mini-split HVAC brand that combines Italian-inspired styling with inverter-driven heating and cooling technology. In North America, Bravo equipment is distributed and supported by Comfortside, with product documentation, technical support, and warranty resources available for homeowners and licensed contractors.

How efficient are Bravo mini-split systems?

Bravo uses inverter technology to adjust compressor output as the heating or cooling load changes. Current Milano configurations are published with efficiency ratings as high as 24 SEER2, although the certified rating depends on the exact outdoor unit, indoor-unit combination, and installation. Check the product documentation and AHRI information for the specific system.

What should I do if a Bravo system displays an error code?

Confirm that electrical power is available, the remote settings are correct, the filters are reasonably clean, and the air inlets and outlets are unobstructed. If the code remains, stop operating the equipment and contact the installing contractor or a licensed HVAC technician. Do not open the refrigerant circuit or electronic components yourself.

Which indoor-unit styles are available from Bravo?

Depending on the product family, Bravo offers high-wall units, ceiling cassettes, slim-duct units, and universal floor/ceiling units. This allows the system design to match the room layout, ceiling space, appearance, and airflow needs of each zone.

Where can I find Bravo manuals and technical information?

Bravo provides product manuals, troubleshooting guides, warranty information, and other technical resources through its official support websites. Use the exact indoor and outdoor model numbers when selecting documentation because wiring, piping, controls, capacities, and operating limits can differ between models.

Can different Bravo indoor-unit styles be used on the same multi-zone system?

Compatible Bravo Milano multi-zone outdoor units can support approved combinations of wall-mounted, ceiling cassette, slim-duct, and other matching indoor units. The installer should confirm that every indoor model, total connected capacity, line size, and zone combination is approved for the selected outdoor unit.

Can Bravo systems provide heating and cooling in extreme outdoor temperatures?

Bravo publishes extended operating ranges on select Milano systems, including heating operation down to approximately -13°F and cooling operation up to approximately 125.6°F. Operating limits are model-specific, and available capacity normally changes as outdoor temperature changes, so review the exact performance data before relying on a unit for extreme-weather heating or cooling.

What types of mini-split systems does Bravo offer?

Bravo offers single-zone and multi-zone mini-split solutions. The current lineup includes wall-mounted systems along with compatible ceiling cassette, slim-duct, and universal floor/ceiling indoor-unit options. Available capacities, combinations, and features vary by series and model.

Does a Bravo mini-split need professional installation?

Yes. Bravo systems are intended to be installed and commissioned by a licensed HVAC professional. Correct installation includes equipment matching, electrical work, refrigerant piping, pressure testing, evacuation, drainage, startup, and verification of operation. Licensed installation is also required for Bravo Limited Warranty eligibility.

What refrigerant do current Bravo mini-split systems use?

Current Bravo Milano and Roma mini-split lines use R32 refrigerant. R32 systems require the correct tools, procedures, approved components, and installation practices, so refrigerant work should be handled only by a qualified HVAC professional. Always verify the refrigerant shown on the exact unit nameplate.

What information is needed to register a Bravo system?

Have the model and serial number for each indoor and outdoor unit, the installation date, the owner contact and installation-address information, the installing contractor or dealer information and HVAC license number, and the purchase date and seller information when applicable.

What routine maintenance does a Bravo indoor unit need?

Keep the return-air area and supply outlet unobstructed, and clean the reusable filters regularly according to the owner manual. Filters can generally be vacuumed or rinsed with lukewarm water and must be fully dry before reinstallation. Turn off power before cleaning, and use a licensed professional for deep cleaning, electrical work, or refrigerant service.

Does Bravo offer both single-zone and multi-zone systems?

Yes. Bravo offers single-zone systems for one area and Milano multi-zone systems that can connect several compatible indoor units to one outdoor condenser. Select Milano configurations support up to five zones, but the approved indoor-unit combination and connected capacity must be verified for the exact outdoor model.

Can Bravo mini-splits be controlled from a smartphone?

Compatible Bravo systems can be controlled through the Bravo SMART App when the indoor unit has built-in Wi-Fi or the correct Wi-Fi module is installed. App compatibility and available controls vary by model, so confirm the product specifications before purchase.

What can the Bravo SMART App control?

On compatible systems, the Bravo SMART App can provide remote on/off control, operating-mode changes, temperature adjustments, fan-speed control, supported louver controls, timers, and schedules. Available functions can differ by indoor unit and app version.

How can I contact Bravo technical support?

Bravo technical and warranty support is provided through Comfortside at 786-953-6706. Published support hours are Monday through Friday, 9:00 a.m. to 5:00 p.m. Eastern Time. Support is offered in English, Spanish, Mandarin, Russian, and Ukrainian. For technical troubleshooting, having a licensed HVAC technician at the equipment is recommended.

How do I start a Bravo warranty claim?

Contact the licensed HVAC technician who installed or services the system and have the technician diagnose the equipment on site. The technician should contact Comfortside Technical Support with the serial number, purchase invoice, licensed-installation invoice, existing case number, and any requested measurements, photos, or diagnostic information.

What warranty coverage is available for Bravo equipment?

Eligible Bravo systems generally include a 5-year limited parts warranty and 7-year compressor warranty when installed by a licensed HVAC technician and registered within 60 days of installation. Coverage is subject to the exact model and the complete written Bravo Limited Warranty terms.

Does the Bravo Limited Warranty cover labor, refrigerant, or shipping?

The published Bravo Limited Warranty is generally parts-only. Labor for diagnosis or replacement, field materials, refrigerant-related costs, travel, transportation, and shipping are not covered unless applicable law requires otherwise. Review the complete warranty document for the exact equipment and location.

When must a Bravo system be registered for warranty coverage?

Bravo states that the system must be registered within 60 days of installation to activate eligible Limited Warranty coverage. The equipment must also be installed by a licensed HVAC technician and remain with the original registered owner at the original installation address.

Is the Bravo Limited Warranty transferable?

No. Bravo states that its Limited Warranty applies only to the original registered owner at the original installation address and does not transfer to a later owner or a different installation location.

What Wi-Fi network is needed to connect a Bravo mini-split?

Bravo recommends a compatible indoor unit or installed Wi-Fi module, an internet-connected 2.4 GHz Wi-Fi network, the network name and password, and a supported phone or tablet with the current Bravo SMART App. Follow the model-specific app manual to place the unit in pairing mode.
