Bravo 36,000 BTU Single Zone Heat Pump System with Multi-Position Air Handler, 208-230V
SKU: BRV-SD36HI-230VO + BRV-MP36AHUW-230VI
Overview
The Bravo 36,000 BTU heat pump system pairs the BRV-SD36HI-230VO outdoor unit with the BRV-MP36AHUW-230VI indoor air handler to deliver dependable year-round comfort for larger residential and light commercial applications. This single-zone system uses R32 refrigerant, operates on 208-230V single-phase power, and is designed for reliable performance across a wide range of outdoor conditions.
The indoor unit features an optimized A-coil, multi-position installation, and support for up to 0.80 in. w.g. external static pressure. The system is also built for easy integration with 24V thermostat controls and compatible third-party setups, while AHRI and ETL certifications support dependable, standards-compliant operation.
Highlights
- Efficient performance: This pairing is rated at 17.0 SEER2 and 10.4 EER2 in the provided specs.
- Flexible installation: Supports horizontal left, horizontal right, vertical up, and vertical down configurations.
- Consistent airflow: ECM fan motor uses constant torque technology for dependable air delivery in demanding applications.
- External static pressure: Supports up to 0.80 in. w.g. for more flexible ducted system design.
- Optional insulation upgrade: 1 inch R4.2 fiberglass-free insulation helps reduce condensation and improve efficiency.
- Auxiliary heat ready: Supports an optional electric heat kit up to 20kW for enhanced heating capability.
- Control flexibility: Compatible with 24V thermostat controls, and the provided feature list also notes a wired controller with built-in WiFi.
- Adaptive operation: Adaptive Control System helps optimize performance across changing conditions.
- Cold-weather protection: Crankcase heater comes equipped as standard.
- Service-friendly design: Built for easy maintenance and dependable long-term use.
What’s Included
- Indoor unit: BRV-MP36AHUW-230VI
- Outdoor unit: BRV-SD36HI-230VO
- Wired controller
Indoor Specs
| Spec | Details |
|---|---|
| Model | BRV-MP36AHUW-230VI |
| Power supply | 208-230V, 1Ph, 60Hz |
| Communication wiring | AWG 25x3 |
| Cooling capacity | 36,000 BTU/h (8,300 to 38,900) |
| Cooling input | 3,462 W (710 to 4,500) |
| Cooling rated current | 15.5 A (4.7 to 18.3) |
| EER / EER2 | 10.4 |
| SEER / SEER2 | 17.0 |
| Heating capacity at 47°F | 36,000 BTU/h (6,700 to 41,300) |
| Heating input at 47°F | 3,050 W (460 to 3,550) |
| Heating rated current at 47°F | 13.5 A (2.5 to 15.6) |
| COP | 3.45 W/W |
| Indoor fan motor qty | 1 |
| Indoor fan motor input | 375 W |
| Indoor fan motor RLA | 3.6 A |
| Indoor air flow | 1241 / 901 CFM |
| ESP range | 0 to 0.8 in. w.g. |
| Indoor noise level | 48 / 39 dB(A) |
| Dehumidification | 3.97 L/H |
| Unit dimensions (W x D x H) | 21-1/32 x 21-1/32 x 49-7/32 in. |
| Packed dimensions (W x D x H) | 24-13/32 x 26-37/64 x 50-13/64 in. |
| Net / gross weight | 137 / 151 lbs |
| Drain connection | 3/4 in. |
| Refrigerant piping | 3/8 in. liquid, 3/4 in. gas |
| Design pressure | 609 / 174 PSIG |
| Controller | Wired controller |
| Room temperature range, cooling | 60 to 90°F |
| Room temperature range, heating | 60 to 90°F |
Outdoor Specs
| Spec | Details |
|---|---|
| Model | BRV-SD36HI-230VO |
| Power supply | 208-230V, 1Ph, 60Hz |
| Minimum circuit ampacity | 25 A |
| Maximum fuse | 30 A |
| Compressor model | KTM240D57UMT |
| Compressor type | Twin-rotary |
| Compressor capacity | 36,000 BTU/h |
| Compressor input | 3,462 W (710 to 4,500) |
| Compressor rated current (RLA) | 2.50 A |
| Refrigerant oil | VGA74 / 22.6 oz |
| Outdoor fan motor qty | 1 |
| Outdoor fan motor input | 150 W |
| Outdoor fan motor RLA | 2.50 A |
| Outdoor airflow (max) | 2,650 CFM |
| Outdoor noise level (max) | 56 dB(A) |
| Throttle type | Capillary |
| Unit dimensions (W x D x H) | 37-63/64 x 31-57/64 x 15-3/4 in. |
| Packed dimensions (W x D x H) | 42-1/8 x 34-41/64 x 20-43/64 in. |
| Net / gross weight | 132 / 140 lbs |
| Refrigerant type | R32 |
| Factory precharge | 24.6 ft |
| Additional charge for 3/8 in. liquid pipe | 0.52 oz |
| Refrigerant piping | 3/8 in. liquid, 3/4 in. gas |
| Maximum pipe length | 246 ft |
| Maximum level difference | 98.4 ft |
| Ambient range, cooling | 5 to 131°F |
| Ambient range, heating | -4 to 75°F |
Important
Professional installation is recommended. Verify electrical requirements, auxiliary heat compatibility, line set sizing, and control compatibility before installation.
