Weekday and Weekend Programming
Create one schedule for Monday through Friday and another for Saturday and Sunday to match your typical weekly routine.
Click image to zoom
Armbridge AB-24V-UTS 24V Universal Thermostat
$75.00
Currently unavailableContact us for lead time
Recommended Add-Ons
Compatible accessories for this system
Must haves for best Installation
Loading recommended accessories…
Brand Information
ARMBRIDGE
- Support Number
- (800) 977-0722
- Official Site
- ARMBRIDGE Official Site
Product Overview Full product description Read the longer product copy, features, and application notes. +
Armbridge • Programmable HVAC Thermostat
Armbridge AB-24V-UTS 24V Universal 5+2 Programmable Thermostat
A programmable thermostat for compatible single-stage heating and cooling systems, including furnaces, air conditioners, heat pumps, and heat-only or cool-only applications.
1 Heat / 1 Cool
Single-stage operation
5+2 Schedule
Weekday and weekend programming
24V or Battery
Flexible power options
°F or °C
Selectable temperature display
Simple temperature control
Programmable control for compatible heating and cooling systems
The Armbridge AB-24V-UTS is a programmable thermostat designed to operate compatible systems with one stage of heating and one stage of cooling.
Its 5+2 programming allows separate weekday and weekend schedules. The thermostat also includes adjustable heating and cooling cycle settings, temperature calibration, filter-use tracking, and selectable Fahrenheit or Celsius display.
5+2 programmable
1 heat / 1 cool
Battery or 24V power
Filter-use counter
Low-battery indicator
Temperature calibration
Single-Stage System Control
Designed to control compatible systems with one stage of heating and one stage of cooling.
Compressor Delay Protection
A selectable five-minute delay helps prevent rapid compressor restarting after the system shuts off or loses power.
Temperature Hold Function
The hold control maintains the selected temperature without following the programmed schedule until normal scheduled operation is resumed.
Filter-Use Reminder
The adjustable filter-use counter tracks operating days and displays a reminder when the selected service interval is reached.
Adjustable Temperature Display
Choose between Fahrenheit and Celsius and calibrate the displayed temperature when an adjustment is required.
Compatible System Applications
| System Type | Compatibility |
|---|---|
| One-stage heating and one-stage cooling | Yes |
| Gas or oil heating systems | Yes |
| Electric furnaces | Yes |
| Heat pumps without auxiliary or emergency heat | Yes |
| Heat-only systems | Yes |
| Floor or wall furnaces | Yes |
| Cool-only systems | Yes |
| Millivolt systems | Yes |
Product Specifications
| Specification | Details |
|---|---|
| Brand | Armbridge |
| Model / SKU | AB-24V-UTS |
| Product type | Programmable HVAC thermostat |
| Programming format | 5+2 programmable schedule |
| Heating stages | 1 |
| Cooling stages | 1 |
| Power options | Battery powered or 24V hardwired |
| Temperature display | Selectable Fahrenheit or Celsius |
| Compressor delay | Five minutes, selectable on or off |
| Cycle adjustment | Separate heating and cooling swing adjustments |
| Additional functions | Temperature hold, display calibration, low-battery indicator, and adjustable filter-use counter |
| Heat pump compatibility | Heat pumps without auxiliary or emergency heat |
This thermostat must be installed by a trained and experienced
technician. Confirm the HVAC system type, wiring, power requirements,
and thermostat compatibility before installation. This model is not
intended to control auxiliary or emergency heat.
