Cooper & Hunter Multi-Zone 3 Ton 230V Olivia Series, 36K BTU Air Conditioner, Ductless Mini Split with 9K+9K+18K BTU Wall Mounts, R410A, 23.9 SEER2 Inverter Heat Pump, 230V, Three Head (3 Heads)
Summary
With its high efficiency/high SEER compressor and auto swing louvers, this newest model Cooper & Hunter ductless mini split will both heat and cool your home or office. The DC inverter heat pump pulls heat from the air down to temperatures as low as -13°F! You are well protected by a seven year warranty on the compressor, a five year parts warranty (must be installed by a licensed HVAC technician), abundant parts availability and smart, experienced technicians should you ever need assistance. This model features a safe and rugged Toshiba-GMCC inverter compressor.
Included in Your Order:
Cooper & Hunter Multi Zone Concealed Duct Mini Split System 36,000 BTU Inverter with Heat Pump
Outdoor Unit: 36,000 BTU (1pc) - Model: CH-36MES-230VO
Indoor Units:
- 9,000 BTU (2pcs with remotes) - Model: CH-09MOLVWM-230VI
- 18,000 BTU (1pc with remote) - Model: CH-18MOLVWM-230VI
Wi-Fi Adapter (17310900A05963)
Wireless Remote Controls (3)
Installation Manual
User's Manual
Manufacturer Warranty
SEER 1: 23
SEER2: 23.9
Key Features:
- High efficiency 23.9 SEER2 rating
- Three-zone configuration with mixed capacity indoor units
- Auto-Swing horizontal/vertical louvers
- Heating operation down to -13°F
- Turbo Mode for rapid cooling/heating
- Self-Clean function prevents mold buildup
- Follow Me temperature sensing
- Smart control via Wi-Fi and C&H Remote app
- Toshiba-GMCC inverter compressor technology
- Energy Star certified
Important
Cooper&Hunter Limited Warranty terms are available if the product is registered within 60 days of installation. THE UNIT(S) MUST BE INSTALLED BY A LICENSED HVAC PROFESSIONAL FOR VALID WARRANTY. Registration can be completed online or by phone.
Warranty
- 7 year compressor limited warranty
- 5 year parts limited warranty (must be installed by a licensed HVAC technician)
- 1 year remote control
Technical Information
Indoor unit: CH-09MOLVWM-230VI (9,000 BTU Indoor Wall Mount Unit)
Specification | Value |
BTU Rated | 9,000 |
Power source | 208/230V, 1Ph, 60Hz |
Minimum Circuit Ampacity (MCA) | 3A |
Max Fuse Size | 15A |
Indoor Air Flow (Turbo/Hi/Med/Lo) | 341/291/194/152 CFM |
Noise Level (Hi/Med/Lo) | 40/35/23.5 dB(A) |
Dimensions (W×D×H) | 31.57×7.87×11.61 inches |
Packing Dimensions | 34.45×11.22×14.96 inches |
Net/Gross Weight | 18.96/24.25 lbs |
Operating Temp (Cooling) | 60-90°F |
Operating Temp (Heating) | 32-86°F |
Refrigerant Lines | 1/4" (liquid) / 3/8" (gas) |
Indoor unit: CH-18MOLVWM-230VI (18,000 BTU Indoor Wall Mount Unit)
Specification | Value |
BTU Rated | 18,000 |
Power source | 208/230V, 1Ph, 60Hz |
Minimum Circuit Ampacity (MCA) | 3A |
Max Fuse Size | 15A |
Indoor Air Flow (Turbo/Hi/Med/Lo) | 760/530/458/382 CFM |
Noise Level (Hi/Med/Lo) | 46/40/25 dB(A) |
Dimensions (W×D×H) | 42.64×9.61×13.23 inches |
Packing Dimensions | 45.47×16.34×12.40 inches |
Net/Gross Weight | 29.54/37.48 lbs |
Operating Temp (Cooling) | 60-90°F |
Operating Temp (Heating) | 32-86°F |
Refrigerant Lines | 1/4" (liquid) / 1/2" (gas) |
Outdoor unit: CH-36MES-230VO (36,000 BTU Outdoor Condenser Unit)
CH-36MES-230VO | |
Specification | Details |
Power Supply | 208~230V, 60Hz, 1Ph |
Rated Capacity (range) (cooling) | 36,000(8,209~40,555) |
Rated Capacity (range) (heating at 47F°) | 37,000(8,008~44,632) |
EER2 | 11.7 |
SEER 2 | 23.9 |
Minimum Circuit Ampacity (Outdoor unit) A | 25 |
Max. Fuse (Outdoor unit) A | 40 |
Refrigerant Type Charged | R410A |
Refrigerant Precharge | Up to 100 oz |
Outdoor Noise Level (Sound Pressure) dB(A) | 63 |
Dimensions (W×D×H) | 37.24×16.14×31.89 inches |
Net/Gross Weight | 169.09/181.44 lbs |
Cooling °F | 5~122 |
Heating °F | -13~75 |
Max Pipe Length | 262 ft |
Max Height Difference | 49.21 ft |
Performance Features
- Precise ±1°F temperature maintenance
- 291-760 CFM adjustable airflow per indoor unit
- 7.14 pints/hour dehumidification capacity
- 3.5 COP heating efficiency at 47°F
- Automatic reverse cycle defrost
- Filter cleaning reminder system
- Refrigerant leak detection with auto-shutdown
